Stacer 609 Plate Ocean Ranger Hard Top SDF XLS Boat,
Move Trailers 2000 ATM Tandem Axle 13" Mech Braked Trailer &
Mercury Marine 135HP FourStroke Outboard

Kit Inclusions: Boat, Trailer, & Motor

Stacer 609 Plate Ocean Ranger Hard Top SDF XLS

Stacer's Plate boat range is hot off the production line and is built to be the perfect companion for the offshore fisherman. The plate range features a massive 20 models in a selection of side and centre consoles, cabin and hard top designs. With all the features that matter most to the bluewater fisherman, Stacer's plate range offers the perfect package!

609 Ocean Ranger Hard Top

The new 609 Ocean Ranger now features more freeboard at 730mm creating better stability. The 609 is rated to 150Hp with a 135L fuel tank.

Boat Features

  • 12 Volt Power Outlet
  • Anchorwell
  • Bow Sprit
  • Burley Bucket
  • Cabin Footrest
  • Cast Welded Rod Holders (6)
  • Fold Down Drink Holders
  • Live Bait Tank Alloy & Glass Back Deck
  • Marine Radio
  • Maxi Bracket
  • Outrigger Mounting Plates
  • Rear Ladder
  • Scuppers
  • Twin Battery Box & Switch
  • Windscreen Wiper
  • X-Bollard
  • Self Drain Floor Treadplate
  • Cabin Storage
  • Carpet: Hard Top Roof
  • Evo Advance Hull
  • Fully Weld Gunnels & Side Decks
  • Rod Holders (5) Reel Easy
  • Side Pockets
  • Transducer Brackets x 2
  • Trim Tabs
  • Welded Gunnels and Top Decks
  • Painted Hull
  • Rails: Bowrails
  • Rails: Cabin Grabrail
  • Rails: Side
  • Rails: Transom
  • Cabin Hatch
  • Cabin Windows
  • Seats: Ocean Pro
  • Hydraulic Steering
  • Transom Door

Boat Options

  • Bait & Fishing Station
  • Carpet: Cabin Lining
  • Cigarette Lighter Outlet
  • Deck Wash
  • Drum Winch
  • Hand Wash
  • LED Lights Hard Top
  • Savwinch 1000SS
  • Savwinch Electronic Free Fall
  • Sound System & Speakers
  • Dive Ladder
  • Bow Bunk Infill Cushion
  • Ice Box 70L
  • Seats: Cabin Backrest
  • Seats: Cabin Cushions
  • Seats: Folding Rear Lounge 3/4
  • Seats: Helm Slider
  • Seats: Navigator Slider
  • Vinyl Wrap

Move Trailers Aluminium 2000 ATM Tandem Axle 13" Roller Mechanical Braked Trailer - TAP2000T13RB
Suitable for 5.7m - 6.1m Boats

You want a strong trailer supporting your pride and joy and this aluminium frame offers the best with a swing jockey wheel as standard and multi-roller set-up for easy retrievals.

Trailer Features:

  • 13 Inch Alloy Wheels
  • 5 Alloy Cross Members
  • 50mm Braked Coupling (2 Tonne)
  • 7-Pin Plug
  • 45mm Square Axle
  • Clearance Lights
  • Disc Brakes
  • Easy Loader Cradle
  • Forward-Facing White Light
  • Swing-Up Jockey Wheel
  • LED Lights
  • 10.5:1 Winch

Trailer Options

  • Spare Wheel & Carrier
  • Trailer Walkway

Mercury Marine 135HP FourStroke Outboard - Electric Start Extra Long Shaft

FourStroke
Make every minute count. Every spot, every tow, every cast. With innovative technologies, simple maintenance and efficient performance, Mercury fourstroke outboards were engineered to elevate every moment on the water.

The entire fourstroke outboard family features efficient, lightweight designs that ensure no power goes wasted. It is worry-free boating that is easy to own and fun to drive. With features ranging from a no-spill oil change system and easy-access fuel filter, to a valve train that remains maintenance-free for the life of your engine, Mercury fourstroke outboards are easy to maintain for lasting peak performance.

It is simple. You have places to go, and a Mercury fourstroke outboard is the easiest way to get there. Their high-displacement powerheads deliver impressive torque, speed and acceleration - with reliability you can count on. It is everything you need to get more out of your time on the water.

Embrace Possibility.
Mercury FourStroke outboard motors are incredibly powerful and efficient, and they feature a wide range of applications. Crafted for less weight and high displacement, they generate abundant torque and immediate power. And because they don’t have to work as hard as heavier engines or those with lower displacement, they make boats plane faster and accelerate better, and they provide optimal fuel efficiency at cruising speed.

FourStroke Advantages:

  1. Corrosion Resistance: Advanced alloys. Durable coatings. Sealed electronics. Easy-to-use freshwater flush system. Fourstroke outboards come packed with premium corrosion-preventive technology that enables them to stand up to the most demanding marine environments.
  2. Superior Control: With a choice of tiller or remote steering and compatibility with advanced SmartCraft® features such as Troll Control and Active Trim, you can optimise your engine for total command of all your adventures.
  3. Go Farther: A host of efficiency-enhancing features such as Advanced Range Optimisation (ARO), a closed-loop fuel system and a hydrodynamic gearcase optimise fuel economy so you can go farther on every tank.
  4. Power and Flexibility: A Mercury 250 or 300hp fourstroke outboard is the answer for fishing, cruising or all-around fun. They are ideal for powering a range of boats and come in four colour options to match your boat and style.

Motor Features:

  • High-output alternator: A powerful alternator - 60 amps on the 150hp outboard and 35 amps on 75 to 115hp outboards – helps keep batteries charged and your onboard electronics running all day.
  • Extra charging power: Idle charge battery-management technology on the 150hp engine automatically increases idle rpm to boost alternator output and recharge low batteries.
  • Command Thrust gearcase: Available for the 90 and 115hp outboards, the Command Thrust gearcase is designed to turn larger props. It helps get heavy boats on plane more easily and hold them there at lower speeds without impacting the top speed.
  • Tiller handle: With a range of adjustments and ergonomic controls, the available advanced tiller for 90 to 115hp models or Big Tiller for the 150hp engine puts you in complete command of your adventures.
  • Electronic Fuel Injection (EFI): From the moment you crank the engine to the moment you drop the throttle, EFI technology responds with instant power. Surefire starting in all weather conditions. Smooth, efficient acceleration. Maximum capability.

After 50 years in the industry, Stacer boats has established a solid reputation for inherent reliability and longevity. Whether you're an angler, a first-time boat buyer, or an experienced fisherman, we want you to enjoy all the benefits of a product built to go the distance.

Boat Specifications:

Length Maximum 6.23m
Beam 2.4
Max HP 150hp
People Max 5
Boat Weight 996kg
Transom Shaft Length XLS
Top Sides 4mm
Bottom Sides 5mm
Transom Material 4.0mm


Trailer Specifications:

Product TypeTrailer
Boat Size5.7m - 6.1m
Tare Weight440kg
Aggregate Trailer Mass2000kg
Tyre165
Gross Trailer Mass2000kg
Width Between Guards1.8m
Springs6
Length Overall6.97m
Width Overall2.28m
Wheel13"
Trailer BrakesOverride


Motor Specifications:

Horse power 135
Shaft Length (Inches) 25
Cylinders / Displacement 4 cyl / 3000cc
Steering (Tiller or Remote) Remote
Starting (Manual / Electric) Electric
Fuel Tank -
Standard (STD) Recommended Propeller Enertia
Alternator amp / watt17 amp / 210 Watts
ColourBlack
Compatible with SmartCraft digital technologyYes
Displacement (L)3.0L
Dry weight *lightest model available455 lbs / 206 kg
Engine type8-valve single overhead cam (SOHC)
HP / kW135 / 101
Recommended fuelRegular Unleaded (91 RON)

SKU KIT177-609-2000-1135F23ED
Brand Stacer
